How to Increase the Size of the Logical Volume ?


How to Increase the Size of the Logical Volume ?

Follow the steps below to increase the size of the logical volume and allocate additional space on one of your partitions.

Once logged in, type df -h at the command prompt and hit ENTER. The partition and logical volume sizes will be listed including the used disk space. In the image below, the var logical volume is 4GB. Assume that ~9GB of web content will be uploaded to the /var folder. The disk space needs to be increased before there is enough space to upload the content.

Type ‘df -h‘ and press Enter


Next, type fdisk -l to view the total hard disk(s) size and partitions on the disk. It can also be noticed here that the physical partition /dev/sda3 is using Linux LVM.

Type ‘df -h’ and press Enter


Type the pvs command and press Enter.


As stated above, our scenario requires roughly 9GB of data to be uploaded to the /var folder. Since the logical volume assigned to /var is only 4GB, we will increase this to 10GB using the lvextend command. The command below is to be used as reference only as the parameters will be different depending on your scenario.

The format for the lvextend command is as follows:
lvextend -L +6G /dev/mapper/vg00-var

lvGrow4Type df -h to display the disk free space once again. The lvextend operation finished successfully in the last step however the /dev/mapper/vg00-var size is still only showing 4.0G. This is because, while the logical volume was increased successfully, the file system needs to be extended to take advantage of the full space of the logical volume.

Type ‘df -h’ and press Enter


Type lvs to show the logical volume information once again. Here, we can confirm that the logical volume has successfully been extended to 10 gigabytes. In the next steps, we will increase the file system to match the logical volume size.
Type ‘lvs’ and press Enter


Type mount and press ENTER to display the mounted file systems. From the output, we find that the /dev/mapper/vg00-var logical volume is using xfs (with the introduction of CentOS 6, the default filesystem is ext4).
Type ‘mount’ and press Enter


To increase the file system to match that of the logical volume, we will use the xfs_growfs command if the filesystem uses xfs or resize2fs if the filesystem is ext4.

Typing xfs_growfs /var OR resize2fs /dev/mapper/vg00-var (depending on which filesystem is used on your system) will extend the file system to the 10 gigabyte limit of the logical volume.

lvGrow8Type df -h to display the disk free space to confirm that the file system has been extended.
< lvGrow9

In conclusion, optimizing logical volume size on a Linux Server is pivotal for efficient server management. Implementing size adjustments ensures streamlined operations and enhances overall server performance.
